DMX Touch Wall Color Controllers - Alloy LED

AL-60-03-0003 | AL-60-03-0003-S

The DMX Touch Wall Controller can be used with the Wireless Receiver (AL-60-03-0004 – sold separately) to wirelessly control the color mode, speed, and brightness of both Radialux RGB and RGBW tape lights. It is also compatible with DMX Decoders (see Accessories below) for hard-wired DMX color control, and can connect directly to DMX fixtures. This controller features a touch-sensitive glass interface and is available in a 3 Zone (AL-60-0003) or 3 Scene (AL-60-0003-S) model: the Zone model has the ability to create up to three lighting zones using multiple receivers or decoders; you can save up to three lighting scenes in the 3 Scene model.

Both controllers are easy to install into a standard wall outlet. NOTE: Alloy LED strongly recommends installing these in-wall controllers in a PVC or plastic junction box if they are intended to be used wirelessly.

Quick Specs
  • Operation Voltage: 12-24V DC
  • Signal: DMX512
  • Location: dry
Model
Models
Item Number Model Input Voltage Dimensions DMX Channels
AL-60-03-0003 3 Zones 12-24V DC 4.75 x 3 x 0.4 in. 256
AL-60-03-0003-S 3 Scenes 12-24V DC 4.75 x 3 x 0.4 in. 256
